New 40 meter yagi is a OWA design with excellent bandwidth. Tower is a 140' PiRod 30" face guyed tower with 1.25" sol

Comments

Add a comment

  • José Filipe Simões Júlio on 2016-Mar-10 03:18:08 José Filipe Simões Júlio said

    Hello I would like to know what steps between Ref. / Driver / DIR 1 / DIR 2 as well as the diameters of the tubes and measures the length of the boom.

    I think that this antenna is OWA, Full Size, all elements must be isolated from BOOM, the DRIVEN without hairpin, the antenna has 50ohms.

    Thank you 73.
